Embedded Modules

Advantech embedded modules include: wireless module, wifi module, I/O module, touch module, memory module and storage module. These I/O modules combine with advanced management software for a total solution for all kinds of embedded applications, and all I/O modules are fully compatible with Advantech platforms. What's more, Advantech's SQFlash storage modules include CompactFlash, CFast, SATA SSD and embedded modules, and provide software protection and life monitoring features.

Product Categories

  • Storage Modules

    Advantech Storage Modules includes industrial storage, mSATA, Cfast, CompactFlash (CF card), industrial solid state drive (SSD), SD card and mini SATA. Advantech storage modules combine versatile USB flash storage media with advanced management software as a total solution for all kinds of embedded applications. With Advantech Storage Modules, system integrators and industrial PC venders can easily implement security, backup and recovery functions on their own systems or applications. Advantech Storage Modules provide not only a robust, safe and secure environment with life-span detection and early warning mechanisms, but also offer comprehensive industrial storage: mSATA, Cfast, CompactFlash (CF card), industrial solid state drive (SSD) , SD card and mini SATA.

  • Memory Module

    Advantech Memory module and DRAM modules offer an extensive portfolio of industrial grade un-buffered DIMMs, LONG-DIMM and SO-DIMM which are designed according to the latest JEDEC standards and cover all technologies from DDR to DDR3 in wide temperature ranges (-40 to 85C). Advantech Memory module and DRAM modules' synchronous design allows precise cycle control with the use of system clock. I/O data transactions are possible on both edges of DQS. Range of operation frequencies, and programmable latencies allow the same device to be useful for a variety of high bandwidth, high performance memory system applications.

    • SQR-SD4M

      *JEDEC standard 1.2V (1.26V~1.14V) power supply *JEDEC standard 260-pin Dual In-Line Memory Module *Operating temperature range: -20 °C ≤ TCASE ≤ 85 °C *30u" Gold Finger *100% Screening Test
    • SQR-SD4I

      *JEDEC standard 1.2V (1.26V~1.14V) power supply *JEDEC standard 260-pin Dual In-Line Memory Module *Operating temperature range: -40 °C ≤ TCASE ≤ 85 °C *30u" Gold Finger *100% Screening Test
    • SQR-UD3I

      Industrial Grade DDR3 SODIMM with Thermal Sensor
    • SQR-SD3M

      *JEDEC standard 1.35V power supply *JEDEC standard 204-pin Dual In-Line Memory Module
    • SQR-UD4M

      JEDEC standard 1.2V (1.26V~1.14V) power supply JEDEC standard 288-pin Dual In-Line Memory Module SDRAM operating temperature range: -20 °C ≤ TCASE ≤ 85 °C High-temperature (85 °C)/Low-Temperature (-20 °C) Burn-in Test 30u" Gold Finger 100% Screening Test
    • SQR-UD3M

      Low voltage 1.35V is backward compatible with 1.5V DDR3 module JEDEC standard 204-pin Dual In-Line Memory Module SDRAM operating temperature range: -20 °C ≤ TCASE ≤ 85 °C High-temperature (85 °C)/Low-Temperature (-20 °C) Burn-in Test 30u" Gold Finger 100% Screening Test
    • SQR-SD2I

      Industrial Grade DDR2 SODIMM
    • SQR-SD3I

      *JEDEC standard 1.35V power supply *JEDEC standard 204-pin Dual In-Line Memory Module *Operating temperature range: -40oC ≤ TA≤ 85 oC *30u" Gold Finger *100% Screening Test
  • Embedded Extension Modules

    Advantech's new embedded extension modules (EXM) are standard full-size Mini PCIe modules that come in a variety of I/O interface choices. With EXM, you can simply extend extra interface ports without customization or board modification. This makes EXM modules easier to be integrated and offers high flexibility for a diverse range of embedded, automation, transportation and networking applications.

    • Touch Module

      Advantech’s Embedded Touch Module (ETM) solutions include: Touch screen, Touch board, and Touch sensors, which also provide high reliability, high resolution, and fast conversion times. Advantech’s own application software—TouchWare, decreases integration effort and adds extra value to hardware and software. Currently, our ETM solutions incorporate various touchscreen technologies including Resistive and Surface Acoustic Wave, and later on Capacitive and Infrared types, which are applies to Touch screen, Touch board, Touch sensor applications.
    • CANBus & Interface Card

      Advantech have developed a series of APIs for customers to access Controller Area Network (CANBus) Protocols. Advantech CANBus and Interface Card modules are high-quality developed and manufactured according to each standard. Meanwhile, CANOpen which is license based protocol, is also released with the CANBus modules as an alternative option. The form factors of most modules are combination of full-size Mini PCIe & module types. Advantech I/O modules are as easy to fulfill as different application.
